Phone Features

- 1 VoIP account, Hotline

- Call waiting, Call transfer, Call forward

- Call hold, Mute, Redial, DND

- 3-way conferencing, Speed dial

- Direct IP call without SIP proxy

- Volume control, Ringtone selection

- Tone scheme, System log export

- Integrated Voice Response System



IP PBX System Integration

- Music on hold

- Call park, Call pickup

- Dial plan, Dial now

- Voicemail

- Message Waiting Indication (MWI)

- Distinctive ringtone



Network Features

- SIP v1 (RFC2543), v2 (RFC3261)

- NAT Traversal: STUN mode

- DTMF: In-band, out-of band (RFC2833) and SIP INFO

- Proxy mode and peer-to-peer SIP link mode

- IP Assignment: Static/DHCP

- TFTP/DHCP client

- Telnet/HTTP server

- DNS client



Security

- QoS: IEEE 802.1p/q tagging (VLAN), Layer 3ToS

- Digest authentication using MD5/MD5-sess

- Secure configuration file via AES encryption

- Admin/user configuration mode



Management

- Built-in HTTP web server

- Configuration: browser/phone/auto-provision/IVR

- Auto provision via TFTP/FTP/HTTP/PnP

- Auto provision for firmware, configuration, ringtone etc



Physical Features

- TI TITAN chipset

- 20 keys including 2 programmable keys

- 4 feature keys (Transfer/Hold/Mute/Redial)

- Phone label

- 1xdual-color LED

- 1xRJ45 10/100M Ethernet port

- Desktop with footstand (detachable),

- Wall-mountable

- Power adapter: AC 100~240V input and DC 5V/1.2A Output

- Power over Ethernet (IEEE 802.3af class 1) optional

- Operating humidity: 10~95%

- Storage temperature: up to 60 C
