Ubiquiti Networks UniFi Switch Managed PoE+ US-8-150W Gigabit 8-Port with SFP 150W
Product Highlights
Model#: US-8-150W
Sku: IT1586
MSRP: $249.99
Out of stock
Your Price: $223.00
Model: US-8-150W
Ubiquiti US-8-150W UniFi Switch 8, 150W Managed PoE+ Gigabit Switch with SFP
Versatile Port Configuration
Eight Gigabit RJ45 ports offer convenient different power output options: auto-sensing IEEE 802.3af/at PoE/PoE+ and 24V passive PoE, and two SFP ports provide optical fiber connectivity options to support uplinks of up to 1 Gbps.
Sleek Design and Management
The compact UniFi Switch can be placed on a desktop and integrates with the UniFi Controller software for centralized management of your UniFi devices.
Advanced Enterprise Switching
The UniFi Switch supports VLAN tagging, port isolation, storm control, and guest control.
Specifications US-8-150W
| Dimensions | 204 x 43 x 235 mm (8.03 x 1.69 x 9.25") |
| Weight | 1.7 kg (3.75 lb) |
| Total Non-Blocking Throughput | 10 Gbps |
| Switching Capacity | 20 Gbps |
| Forwarding Rate | 14.88 Mpps |
| Max. Power Consumption | |
| Including PoE Output | 150W |
| Excluding PoE Output | 20W |
| Power Method | 100-240VAC/50-60 Hz, Universal Input |
| Power Supply | AC/DC, Internal, 150W DC |
| LEDs Per Port | |
| RJ45 Data Ports | PoE, Speed/Link/Activity |
| SFP Data Ports | Speed/Link/Activity |
| Networking Interfaces | (8) 10/100/1000 Mbps RJ45 Ethernet Ports (2) 1 Gbps SFP Ethernet Ports |
| Management Interface | Ethernet In-Band |
| Certifications | CE, FCC, IC |
| ESD/EMP Protection | Air: ± 24 kV, Contact: ± 24 kV |
| Operating Temperature | -5 to 40° C (23 to 104° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Shock and Vibration | ETSI300-019-1.4 Standard |
| PoE Per Port | |
| PoE Interfaces | POE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-) 24VDC Passive PoE (Pins 4, 5+; 7, 8-) |
| Max. PoE+ Wattage per Port by PSE | 34.2W |
| Voltage Range 802.3at Mode | 50–57V |
| Max. Passive PoE Wattage per Port | 17W |
| 24V Passive PoE Voltage Range | 20-27V |
Datasheet
