NBE-2AC-13-US-BD1

Ubiquiti


Ubiquiti NanoBeam ac NBE-2AC-13-US 2.4Ghz 13dBi CPE Wireless AP x2 + airCube ACB-AC-US Home Wi-Fi x2


Model#: NBE-2AC-13-US-BD1

Sku: IT1920



MSRP: $487.00


Out of stock

Model: NBE-2AC-13-US (2 Units)

Ubiquiti NanoBeam 2AC 13Dbi 2.4Ghz 802.11N MiMO Antenna, 330+ Mbps, Range 10+ Km (NBE-2AC-13) The NanoBeam 2AC utilizes a stronger RF energy beam width for better noise filtration. It features a one direction focus for a stronger frequency signal.

Innovative Mechanical Design
• Built-in mechanical tilt. The mounting bracket conveniently offers 20° of up-tilt and up to 20° of downtilt.
• Quick assembly. The number of fasteners was reduced to simplify assembly. Tools are required only when the technician mounts the NanoBeam on the pole.
• Easy removal. The antenna feed can be detached with the push of a button.

+

Model: ACB-AC (2 Units)

Introduction

Ubiquiti Networks introduces the airCube, a cost-effective wireless access point for use in your customer deployments.

Wireless Performance:

  • airCube AC Dual-band, 802.11ac, 2x2 MIMO technology for maximum wireless performance:
  • 2.4 GHz radio band Speeds of up to 300 Mbps
  • 5 GHz radio band Speeds of up to 866.7 Mbps

Model: NBE-2AC-13-US (2 Units)

  • Dimensions (Mount Included): 189 x 189 x125mm (7.44 x 7.44 s 4.92")
  • Weight (Mount Included): 530g (1.17lb)
  • Operating Frequency: 2412 -2462 Mhz
  • Gain: 13dBi
  • Networking Interface: (1) 10/100/1000 Ethernet port
  • Enclosure : Outdoor UV Stabilized Plastic
  • Max. Power Consumption: 8.5W
  • Power Supply: 24V, 0.5A Gigabit PoE Adapter (included)
  • Power method: Passive PoE (Pairs 4, 5+; 7, 8 Return)
  • Wind loading: 45.4 N@ 200 km/h (10.2 lbf @ 125 mph)
  • Wind Survivability: 200 km/h (125mph)
  • Certifications: CE, FCC, IC
  • Mounting: Pole-Mount (Kit included) / Wall-Mount (Not Included)
  • ESD/EMP: ±24kV Contact / Air
  • Operating Temperature: 5 to 95% Noncondensing

+

Model: ACB-AC (2 Units)

  • (4) Gigabit Ethernet Ports
  • 24V PoE Passthrough for airMAX CPE
  • Dual-Band, 802.11ac, 2x2 MIMO Technology
  • Up to 1167 Mbps Wi-Fi Data Throughput
  • Up to 300 Mbps in the 2.4 GHz Radio Band
  • Up to 866.7 Mbps in the 5 GHz Radio Band
  • Powered by 24V Passive PoE or Included Power Adapter
