UniFi nanoHD

Democratizing Enterprise Wi-Fi Performance

Deploy the UniFi nanoHD AP in high-density environments requiring maximum wireless performance and minimal footprint. The UniFi nanoHD AP features simultaneous, dual-band, 4x4 MU-MIMO technology and convenient 802.3af PoE compatibility.

4x4 MU-MIMO Technology

Powered by Software Defined Networking

Easily deploy your UniFi Enterprise System using the included UniFi Controller software. Manage thousands of UniFi devices across multiple sites, and scale your network as needed without any ongoing licensing fees.

Product Specifications:

Dimensions

160 x 160 x 32.65 mm
(6.3 x 6.3 x 1.29")

Weight

300 g (10.6 oz)
315 g (11.1 oz)

Networking Interface

(1) RJ45 GbE

Buttons

(1) Reset to Defaults

Power Method

802.3af

Power Supply

48V, 0.5A Gigabit PoE Adapter*

Max. Power Consumption

10.5W

Operating Frequency

2.4 GHz
5 GHz

Max. TX Power

2.4 GHz
5 GHz
23 dBm
26 dBm

Antenna Gain

2.4 GHz - 2.8 dBi
5 GHz - 3 dBi

MIMO

2.4 GHz - 2x2
5 GHz - 4x4

Radio Rate

2.4 GHz - 300 Mbps
5 GHz - 1733 Mbps

Wi-Fi Standards

802.11 a/b/g/n/ac/ac-wave2

Mounting

Wall/Ceiling (Kits Included)

Operating Temperature

-10 to 70° C (14 to 158° F)

Operating Humidity

5 to 95% Noncondensing

Certifications

CE, FCC, IC

PoE Not Included
