wAP 4G kit

Mikrotik


MikroTik RBwAPGR-5HacD2HnD&R11e-4G 2.4/5GHz wAP ac 128MB w/ R11e-4G


Product Highlights
  • Mikrotik wAP 4G kit Small Weatherproof Wireless Access Point 802.11b/g/n with LTE 4G
  • Connect to the wAP’s built-in 802.11b/g/n wireless and access the LTE network from your phone or any other wireless device
  • The wAP LTE also has one 10/100 Ethernet LAN port for your wired devices
  • LTE cards are connected to two internal antennas with u.FL connectors, so if you want, you can unplug the connectors and add your own external LTE antenna for larger coverage
  • RBwAPR-2nD&R11e-4G includes LTE modem that supports LTE bands FDD bands 3 (1800MHz), 7 (2600MHz), 20 (800MHz) and 31 (450MHz), as well as LTE TDD bands 41n (2500MHz), 42 (3500MHz) and 43 (3700MHz)

    • Model#: wAP 4G kit

    Sku: IT2635



    MSRP: $139.99


    Out of stock

    Your Price: $139.99


    MODEL: RBwAPR-2nD&R11e-4G (wAP 4G kit)

    wAP ac 4G kit (RBwAPGR-5HacD2HnD&R11e-4G) with R11e-4G modem for International / USA bands 3, 7, 20, 31, 41n, 42 and 43.

    The wAP ac LTE is a powerful dual-band wireless AP with LTE backup and two Gigabit Ethernet ports, available in several versions.

    Based on the popular wAP form factor, the device is weatherproof and ready for outdoor and indoor installations. You can mount it on walls, ceilings, poles or stand it on a flat surface.

    The device is powered by a four core 716 MHz CPU and 128 MB RAM, capable of handling heavy loads. It’s equipped with two Gigabit Ethernet ports, dual-chain 2.4 GHz and dual-chain 5 GHz wireless for dual concurrent AP coverage. It has a DC power jack, and supports 10-57 V power input by Passive POE or 802.3af/at.

    For the easier use unit is now equiped with a Micro SIM slot.

    Product specifications

    • Product code    RBwAPR-2nD&R11e-4G
    • 10/100 Ethernet ports    1
    • Architecture    MIPSBE
    • Automotive input Voltage    9-30 V
    • CPU    QCA9531
    • CPU core count    1
    • CPU nominal frequency    650 MHz
    • DC jack input Voltage    9-30 V
    • Dimensions    185 x 85 x 30 mm
    • LTE Category    4 (150Mbps Downlink, 50Mbps Uplink)
    • LTE FDD bands    3 (1800MHz) / 7 (2600MHz) / 20 (800MHz) / 31 (450MHz)
    • LTE TDD bands    41n (2500MHz) / 42 (3500MHz) / 43 (3700MHz)
    • License level    4
    • Max power consumption    8 W
    • MiniPCI-e slots    1
    • Number of DC inputs    3 (PoE-IN, Automotive, DC jack)
    • Number of SIM slots    1 Modem (Mini SIM)
    • Operating System    RouterOS
    • PCB temperature monitor    Yes
    • PoE in    Passive PoE
    • PoE in input Voltage    9-30 V
    • Size of RAM    64 MB
    • Storage size    16 MB
    • Storage type    FLASH
    • Tested ambient temperature    -40°C to 60°C
    • Voltage Monitor    Yes
    • Wi-Fi generation    4

    Datasheet

    PDF File MikroTik RBwAPGR-5HacD2HnD&R11e-4G 2.4/5GHz wAP ac 128MB w/ R11e-4G
