EZLC1C1F2WHL28

EzViz


Ezviz L1C1 Smart Security Light Camera 1080p Full HD Starlight Night Vision IP65 MicroSD slot (CS-LC1C-A0-1F2WPFRL)



Product Highlights
  • Dual Lights, 2,000-Lumen Brightness, 1080p
  • Starlight Standard Sensor, Infrared Night Vision up to 25 m / 82 ft.
  • H.265 Video Compression, PIR Motion-Activated Floodlights
  • Advanced Motion Alerts (PIR Sensing + Motion Detection), Built-in Siren, 100 dB
  • Two-Way Talk, Supports MicroSD Card up to 256 GB
  • Model#: EZLC1C1F2WHL28

    Sku: IT3792

    Out of stock

    Your Price: N/A


    Images are brilliant, day and night.

    Thanks to a starlight standard sensor, not just daytime videos are stunning, nighttime images are crisp-clear and bright despite the environmental darkness. Now you can see everything up to 25 meters (82 ft.) away clearly with the camera’s advanced night vision.

    A thoughtful way to illuminate your yard.

    The LC1C is a perfect replacement of yard lights. Designed with flexibility in mind, the LC1C can be rotated to face any direction you need. To use it as a conventional yard light, you may toggle the floodlights on manually and adjust brightness all by using the EZVIZ App.

    Smart lighting.

    Outfitted with a 270-degree PIR sensor, the LC1C’s floodlights automatically light up upon detection of people or animals in the darkness*. You can even configure which zones you’d like to enable PIR motion-activated lighting!

    *When motion is no longer detected, the lights will turn off in 90 seconds.

    Motion alerts are more accurate than ever.

    The LC1C adopts a double-trigger mechanism to boost alert accuracy. By combining the traditional motion detection analytics with a PIR sensor, the LC1C makes sure you only receive attention-worthy notifications.

    Two-way talk.

    The LC1C makes two-way communication even easier with its powerful microphone and speaker. Using the EZVIZ App, both sides can hear each other loud and clear.

    Enhanced connectivity.

    The onboard Wi-Fi module of the LC1C leverages a PA (Power Amplifier) to greatly improve its signal strength and anti-interference capability. In addition, two powerful built-in antennas make sure the LC1C stays online better than ever.

    Multiple storage options.

    The LC1C comes with a built-in MicroSD card slot that can store up to 256 GB of recorded footage. You can also save your images to EZVIZ Cloud* for additional back-up. Thanks to the efficient H.265 video compression technology, the LC1C saves more videos than traditional cameras using the H.264 codec.

    Security at your fingertips.

    With the EZVIZ App, you can capture, save, protect, and share what's valuable to you.

    Model Parameters
    Model CS-LC1C-A0-1F2WPFRL
    System Parameters
    Processor Embedded High-Performance SOC Processor
    Operating System Embedded Linux
    Light Parameters
    Lamp 2
    LED SMD LED
    Brightness 2000LM (+/-10%)
    CRI 80
    Color Temperature 3000K
    Life-Span @B50L70 @Ta 25°C 25000H
    PIR Sensor Detection
    Detection Distance 10 meters (33 feet)
    Detection Range 270-degree
    Camera Parameters
    Resolution 1920 × 1080
    Field of View Horizontal angle: 103°; Vertical angle: 57°; Diagonal angle: 121°
    Night Vision Up to 25 m (82 ft.)
    Video Parameters
    Compression Standard H.264, H.265
    Max. Resolution 1920 × 1080, Full-HD
    Frame Rate 25fps, Adaptive frame rate of network transmission
    DNR 3D DNR
    WDR Supports
    BLC Supports
    Audio Parameters
    Audio Input Built-in Omni-direction microphone
    Audio Output Built-in loudspeaker
    Audio Quality Noise suppression
    Network Parameters
    Wireless 802.11 b/g/n @2.4GHz only (2T2R, dual-antenna)
    Network Configuration Soft AP Configuration
    Storage
    Local Storage Supports Micro SD card (up to 256 GB)
    Cloud Storage EZVIZ Cloud Storage (currently available only in some countries)
    General
    Working Temperature -30°C to 50°C (-20°F to 120°F)
    Working Humidity 0 - 95%
    Power Supply Hardwired (100v - 240v)
    Power Consumption ≤35W
    Ingress Protection Grade IP65 on camera
    Product Dimensions (Height x Width x Depth) 268 x 186 x 185 mm (10.55 x 7.32 x 7.28 inch)
    Package Dimensions 235 x 250 x 235 mm (9.25 x 9.84 x 9.25 inch)
    Weight 1469 g (3.24 lbs)

    Datasheet

    PDF File Ezviz L1C1 Smart Security Light Camera 1080p Full HD Starlight Night Vision IP65 MicroSD slot (CS-LC1C-A0-1F2WPFRL)
