See much more and stay more in the know
With stunning 3K video clarity, it’s hard to miss an important detail. Wherever and whenever, you can view important activities happening at home as if you were right there.
Receive smarter notifications
The camera’s on-board AI algorithm helps it identify moving people and vehicles in particular. It reduces alerts caused by falling leaves or flying insects, and informs you when someone parks in your property area without permission.
Get in touch by simply waving your hand
People can wave at the camera to initiate a video call to your phone². Whenever your kids come home from school, they can let you know.
Rest assured, knowing your night is well protected
The camera makes sure that no one can easily sneak in under the cover of darkness. Choose between the color mode or the infrared mode as you’d like. Or, you can set the camera to the “smart night vision” mode so its vision can automatically switch from black-and-white to full color upon motion detection.
A vigilant guard that works 24/7
The camera features the active defense function to provide an extra layer of protection. Upon detection of intruders, the camera will set off a loud siren and flash two spotlights³ for on-site deterrence.
Greeting can be this easy
Enjoy two-way communications by simply using your phone. Or, pre-record specific voice messages that automatically play when people are detected on camera.
Metal-bodied for tough conditions
The H3 3K features an IP67-rated enclosure made of strong Aluminum alloy. The camera is ready and sturdy for any weather, whether it is rainy, stormy or snowy.
Large, safe storage options that you can trust
You can secure your recorded videos on a local microSD card of up to 512 GB, or subscribe to EZVIZ CloudPlay for fully-encrypted, unlimited cloud storage. A local storage card must be purchased separately.
Enhanced viewing pleasure with smaller video files
Compared to the prevailing H.264 video compression technology, H.265 creates a more fluid viewing experience with recorded 3K videos. Meanwhile, you won’t have to worry about large video files taking up too much of your storage space – H.265 technology reduces their sizes by up to 50%5.
We do our best to protect data and privacy
We design the H3 3K to respect every private space, and to secure every byte of your data. You can set up no-filming privacy zones6 on EZVIZ App to make sure recording only happens when it’s appropriate and allowed. Meanwhile, your recordings is fully encrypted from end to end to stay private and secure.
Specifications | |
---|---|
Model | CS-H3-R100-1J5WKFL |
General | |
Dimensions | 75.5 × 75.5 × 155 mm (2.97 × 2.97 × 6.10 inch) |
Package Dimensions | 227 × 100 × 92 mm (8.94 × 3.94 × 3.62 inch) |
Weight | Net weight: 433 g (15.27 oz) With package: 652 g (23.00 oz) |
IP Grade | IP67 |
Operating Conditions | -30 °C ~ 60 ºC (-22 °F ~ 140 °F ) Humidity 95% or less (non-condensing) |
Camera | |
Image Sensor | 1/2.7”Progressive Scan CMOS |
Shutter Speed | Self-adaptive shutter |
Lens | 2.8mm @ F2.0, viewing angle: 114° (Diagonal), 96° (Horizontal), 51° (Vertical) 4mm @ F2.0, viewing angle: 95° (Diagonal), 80° (Horizontal), 42° (Vertical) |
Minimum Illumination | 0.01 lux @ (F2.0, AGC ON), 0 Lux with IR |
Lens Mount | M12 |
Day / Night Switch | IR-Cut filter with auto-switching |
DNR | 3D DNR |
WDR | Digital WDR |
BLC | Supports |
IR Night Vision Distance | Up to 98 ft / 30 m |
Video & Audio | |
Max. Resolution | 2880 × 1620 pixels |
Frame Rate | Max: 30fps; Self-Adaptive during network transmission |
Video Compression | H.265 / H.264 |
Video Bit Rate | Quad HD+; Full HD; HD; Standard. Adaptive bit rate. |
Audio Bit Rate | Self-Adaptive |
Max. Bitrate | 4 Mbps |
Network | |
Wi-Fi Standard | IEEE802.11b, 802.11g, 802.11n |
Frequency Range | 2.4 GHz ~ 2.4835 GHz |
Channel Bandwidth | Supports 20 MHz |
Security | 64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK |
Transmission Rate | 11b: 11 Mbps, 11g: 54 Mbps, 11n: 150 Mbps |
Wi-Fi Pairing | AP Pairing |
Protocol | EZVIZ Cloud Proprietary Protocol |
Interface Protocol | EZVIZ Cloud Proprietary Protocol |
Wired Network | RJ45 × 1 (10M / 100M Adaptive Ethernet Port) |
Function | |
Detection | AI-Powered Human / Vehicle Shape Detection, Waving-Hand Detection, Motion Detection |
Customized Alert Area | Supports |
Integration | Works with Alexa, Google Assistant, IFTTT |
General Function | Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark |
Storage | |
Local Storage | Supports microSD card (Up to 512 GB) |
Cloud Storage | Supports EZVIZ CloudPlay storage (Subscription required) |
Power | |
Wiring | Hard-Wired |
Power Supply | DC 12V / 1A |
Power Consumption | Max. 8W |
In the box | |
In the box | - EZVIZ H3 3K Camera |
- Drill Template | |
- Screw Kit | |
- Waterproof Kit | |
- Power Adapter | |
- Regulatory Information | |
- Quick Start Quide | |
Certifications | |
Certifications | CE / FCC / UKCA / UL / WEEE / RoHS / REACH |
