RBD53G-5HacD2HnD-TC&EG12-EA

Mikrotik


MikroTik RBD53G5HacD2HnDTC&EG12EA 2.4/5GHz Chateau LTE12 2.5dBi



Product Highlights
  • Chateau LTE12 also known as RBD53G-5HacD2HnD-TC&EG12-EA is a high-speed, dual-band home access point with CAT12 LTE. Chateau also features 5 x Gigabit Ethernet ports and a full size USB port
  • Strong dual-chain dual-band 2.4/5 GHz wireless for concurrent coverage will solve most interference issues in a crowded environment
  • Not only our RouterOS software comes with robust security options, we also focus on the production security
  • Reach speeds of up to 600 Mbps with carrier aggregation, as CAT12 allows devices to use three bands at the same time
  • Chateau LTE12 provides better responsiveness in a crowded environment and higher efficiency for weaker signal situations in the countryside
  • Model#: RBD53G-5HacD2HnD-TC&EG12-EA

    Sku: IT4307



    MSRP: $239.99


    Out of stock

    Your Price: $239.99


    MODEL: RBD53G-5HacD2HnD-TC&EG12-EA

    Let’s face it – most of the standard issue access points can’t really satisfy the extremely diverse client base – they either lack features, users want more speed and higher gain, the price is too high or they look weird. We decide to take all the aspects that are important for most home users and create a single device that will make them happy – this is the MikroTik Chateau. It is a high-speed, dual-band home access point with CAT12 LTE – for really fast Internet anywhere, anytime. But LTE is not the only option – Chateau also features 5 x Gigabit Ethernet ports and a full size USB port.

    Strong dual-chain dual-band 2.4/5 GHz wireless for concurrent coverage will solve most interference issues in a crowded environment. For example, a client can simultaneously use the 2.4 GHz channel for all household mobile devices and reserve the 5 GHz channel for tasks that are sensitive to packet loss – such as streaming high-quality videos.

    Not only our RouterOS software comes with robust security options, we also focus on the production security. There is no outsourcing, every device is assembled in our premises and all the components come from reputable, trusted partners – such as Qualcomm. We cooperate with European law-makers and work hard to ensure full compliance with all the necessary safety policies. MikroTik is all about smooth, long-term cooperation without surprises.Not only our RouterOS software comes with robust security options, we also focus on the production security. There is no outsourcing, every device is assembled in our premises and all the components come from reputable, trusted partners – such as Qualcomm. We cooperate with European law-makers and work hard to ensure full compliance with all the necessary safety policies. MikroTik is all about smooth, long-term cooperation without surprises.

    Specifications

    • Product code    RBD53G-5HacD2HnD-TC&EG12-EA
    • Architecture    ARM 32bit
    • CPU    IPQ-4019
    • CPU core count    4
    • CPU nominal frequency    716 MHz
    • Dimensions    240 x 156 x 44 mm
    • License level    4
    • Operating System    RouterOS (compatible only with v7.0 and above)
    • Size of RAM    256 MB
    • Storage size    16 MB
    • Storage type    FLASH
    • Tested ambient temperature    -40°C to 70°C

    Powering

    • Number of DC inputs    1 (DC jack)
    • DC jack input Voltage    12-28 V
    • Max power consumption    23 W
    • Max power consumption without attachments    17 W

    Mobile

    • 3G Category    R8 (42.2Mbps Downlink, 11.2Mbps Uplink)
    • 3G bands    1 (2100MHz) / 5 (850MHz) / 8 (900MHz) / 3 (1800MHz)
    • LTE Category    12 (600Mbps Downlink, 150Mbps Uplink)
    • LTE FDD bands    1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz) / 28 (700MHz)
    • LTE TDD bands    38 (2600MHz) / 40 (2300MHz) / 41 (2500MHz)

    Wireless

    • AC speed    AC1200
    • Wireless 2.4 GHz Max data rate    300 Mbit/s
    • Wireless 2.4 GHz number of chains    2
    • Wireless 2.4 GHz standards    802.11b/g/n
    • Antenna gain dBi for 2.4 GHz    3
    • Wireless 2.4 GHz chip model    IPQ-4019
    • Wireless 2.4 GHz generation    Wi-Fi 4
    • Wireless 5 GHz Max data rate    867 Mbit/s
    • Wireless 5 GHz number of chains    2
    • Wireless 5 GHz standards    802.11a/n/ac
    • Antenna gain dBi for 5 GHz    5.5
    • Wireless 5 GHz chip model    IPQ-4019
    • Wireless 5 GHz generation    Wi-Fi 5

    Ethernet

    • 10/100/1000 Ethernet ports    5

    Peripherals

    • Number of SIM slots    1 Modem (Micro SIM)
    • Number of USB ports    1
    • USB Power Reset    Yes
    • USB slot type    USB type A
    • Max USB current (A)    1

    Datasheet

    PDF File MikroTik RBD53G5HacD2HnDTC&EG12EA 2.4/5GHz Chateau LTE12 2.5dBi
